| Connectivity |
| Standard connectivity |
| Centronics parallel, IEEE 1284-compliant (ECP), USB 2.0 compliant with Windows 2000, XP, 2003 Server, Mac OS 8.x, 9.x, X, 10.x; HP Jetdirect WIO 10/100 Internal Print Server |
|
| Optional connectivity |
| HP Jetdirect 170x, 300x, 500x, 600, 610n, 615n, 620n |
|
| Media handling |
| Duplex print options |
|
| Custom media sizes (imperial) |
| 8.3 to 24 in wide sheets; 24 in rolls |
|
| Media sizes standard (imperial rolls) |
| 8.3- to 24-in wide sheets, 24-in rolls |
|
| Document finishing |
| Single-sheet feed, roll feed, automatic cutter |
|
| Media types |
| Bright white inkjet paper (bond), translucent bond, natural tracing paper, vellum, clear film, matte film, coated paper, heavyweight coated paper, high-gloss photo paper, semi-gloss photo paper, paper-based semi-gloss, satin poster paper, studio canvas, banners with Tyvek, colorfast adhesive vinyl |
|
| Standard paper handling (input) |
| Sheet feed, roll feed, automatic cutter |
|
| Media sizes supported (imperial) |
| ANSI A, ANSI B, ANSI C, ANSI D, ARCH A, ARCH B, ARCH C, ARCH D |
|
| Memory |
| Memory maximum |
|
| Standard memory |
|
| Networking |
| Network ready |
|
| Performance |
| Memory buffer |
|
| Power |
| Power consumption (maximum) |
|
| Power supply required |
| Line voltage 100 to 240 VAC (+/- 10%) auto-ranging, 50/60 Hz, 3 amps maximum |
|
| Printing |
| Print cartridges |
| 4 (1 each black, cyan, magenta, yellow) |
|
| Ink types |
| Dye-based (color), pigment-based (black) |
|
| Color printing supported |
|
| Print languages standard |
| Adobe PostScript 3, HP-GL/2, HP RTL, CALS G4, (TIFF and JPEG files from UNIX, and Linux via ZEHRaster Plus) |
|
| Print length maximum (imperial) |
|
| Print resolution black (best) |
| 2400 x 1200 dpi on HP Premium Photo paper |
|
| Print resolution color (best) |
| 2400 x 1200 dpi on HP Premium Photo paper |
|
| Print resolution technology |
| HP Color Layering Technology |
|
| Typefaces included |
| 136 PostScript® built-in Roman fonts, Asian PostScript fonts in the box, Morisawa fonts for Japan, support for Sandoll, Hancom, and Yoon PS fonts and Arphic for Taiwan |
|
| Print technology |
|
| Print heads |
| 4 (1 each black, cyan, magenta, yellow) |
|
| Designjet model size (imperial) |
|
| Software |
| Software included |
| Microsoft Windows 2000, XP Home, XP Professional, Server 2003; AutoCAD 2000-2004, Release 13, 14; PostScript drivers for Windows 2000, XP Home, XP Professional, Server 2003; Mac OS 8.x, 9.x, X v 10.1.x, 10.2.x, 10.4; drivers for UNIX, TIFF, JPEG and CALS G4 files are accepted via ZEHRaster Plus software |
|
| Printer drivers included |
| Microsoft Windows 2000, XP, Server 2003, AutoCAD 2000-2004, AutoCAD Release 13, 14; PostScript drivers for Windows 2000, XP, Server 2003; Mac OS 8.x, 9.x, X v 10.1.x, v 10.2.x, v 10.3 |
|
| Storage |
| Hard drive capacity |
|
| System |
| Macintosh requirements (minimum) |
| Mac OS 8.x, 9.x, Mac OS X v 10.x |
| Microsoft Windows 2000, XP, Server 2003 |
|
| System requirements (minimum) |
| Mac OS 8.x, 9.x, Mac OS X v 10.x |
| Microsoft Windows 2000, XP, Server 2003 |
|
|
